NF5180M5 Inspur Server 2.5x10 4x3.5 4210R 16G 2TB SATA 2xGE 550W Rail

Inspur NF5180M5 is a high-end, dual-socket and rack-mounted 1U server, which is designed on the basis of the new generation of Intel® Xeon® scalable processors, and designed for cloud computing, big data and other application scenarios that have a requirement on the space deployment and high performance. This server has high quality and high reliability on the performance, storage and extension, and makes innovations and breakthroughs on computing performance, flexible configuration and intelligent management.

Features and Specifications
Processor
Processor Type	Intel® Skylake Family (supports up to two 205W processors)
	Intel® Cascade Lake Family (supports up to two 205W processors)
Chipset
Chipset Type	Intel® C62x Chipset Family
Memory
Memory Type	ECC Registered DDR4, RDIMM, LRDIMM, NVDIMM
Memory Slot Qty.	24
Total Memory	Supports up to 3TB (128GB per memory module)
Capacity
I/O
USB	3.5x4 model:
	2 rear USB3.0 ports, 1 front USB3.0 port, 1 front USB2.0 port and 1 built-in USB3.0 port 2.5x10 model:
	2 rear USB3.0 ports, 2 front USB2.0 ports and 1 built-in USB3.0 port
VGA	1 front VGA port
	1 rear VGA port
IPMI	1 RJ45 IPMI port
Display
Controller Type	Integrated in the Aspeed2500 chip, supports up to 1280*1024 resolution
SAS Backplane
SAS3.0 Backplane	Supports hot-plug SAS/SATA/NVME drives
NIC
NIC Controller	Supports OCP/PCIE card
Management
Management Chip	It integrates 1 independent 1000Mbps network interface, special for IPMI remote management.
PCI Expansion Slot	• Onboard: 1 PCI Express 3.0 ×16 slot + 1 PCI Express 3.0 ×24 slot, used to support PCI-E Riser card.
	• The Riser card supports horizontal inserted half-height and full-height cards.
	• Standard configuration:
	PCIE0 slot (CPU0 out): 1 Riser card, supporting 1 PCI Express 3.0 x16 slot
	• Full configuration 1:
	PCIE slot0 (CPU0 out): 1 Riser card, supporting 1 PCI Express 3.0 x16 slot
	PCIE slot1 (CPU0/1 out): 1 Riser card, supporting 1 PCI Express 3.0 x8 slot (CPU0) +1 PCI Express 3.0 x16 slot (CPU1)
	• Full configuration 2:
	PCIE slot0 (CPU0 out): 1 Riser card, supporting 1 PCI Express 3.0 x16 slot
	PCIE slot1 (CPU0/1 out): 1 Riser card, supporting 1 PCI Express 3.0 x8 slot (CPU0) + 4 NVME ports (CPU1)
OCP
OCP Slot	• Onboard: 1 Type A+ slot, 1 Type A+B slot, and 1 Type C slot
	• Supports OCP/PHY card
Drive
Drive Type	SAS, SATA, NVME, SATA M.2, PCIE M.2
External Storage Drive
Optical Drive	Supports external USB drive
TF Card	Built-in TF card
Power
Specification	Supports power supply of 550W/800W/1300W/1600W and above output power; 2 power modules; 1+1 redundancy; supports single-power/dual-power
Power Input	Please refer to the power input on the nameplate label of the host.
Physical
Packing Box	651 width × 247 height × 1031 depth (unit: mm)
Dimensions
Host Machine	435 width × 43 height × 750 depth (unit: mm)
Dimensions
Product Weight	Gross weight of full configuration (Gross weight includes: Host + Packing Box + Rails + Accessory Box)
	2.5x4 model: 26.5kg
	3.5x4 model: 27.2kg
